TDK EFG-03 Overview
The EMC Shop stocks the TDK EFG-03 field generator for rental and fast testing to MIL-STD RS103 at 200V/m. High power amplifiers and test setup accessories are available as well.
[split]
Performance
The TDK RF Solutions EFG-03 is an E-field generator designed to produce controlled, high intensity electric fields over the frequency range of 10 kHz to 100 MHz. The EFG-03 generates a minimum of 500 V/m between the elements. Its capability to handle high input power and its low VSWR makes the EFG-03 a powerful and effective E-field generator.
High Input Power
The EFG-03 utilizes an external load that permits the field generator to handle input power up to 3500 Watts (continuous) without the use of forced air or water cooling. This makes the EFG-03 ideal for immunity test applications which require high input power, high intensity fields in a compact design.
Robust Design
The EFG-03 features an extremely robust transformer design which greatly improves the low frequency response.
Complete Positioning Control
The EFG-03's integrated mast provides complete manual control of height, tilt, and polarization. The EFG-03's positioning gimbal allows manual control of tilt to ± 10° and provides full 360° rotation of the EFG-03 with indexing at 0° and 90° for quick and easy polarization changes. A locking pin secures the mounting arm in position. The EFG-03's mast, base, and mounting arm are constructed of heavy-duty square fiberglass tubing with a protective water seal. The mast features four locking swivel casters for safety and ease of movement.
