Oscilloscopes

Oscilloscopes Test Equipment, Systems & Solutions

•

  Tektronix MSO64-6-B8000 8 GHz Oscilloscope

  SKU: 8880

  Bandwidth: 8 GHz

  Trigger Type: Edge, Pulse Width, Runt, Timeout, Window, Logic, Setup & Hold, Rise/Fall Time, Parallel Bus, Sequence, Visual Trigger

  Peak Detect: 160 ps at all sweep speeds

  Channels: 4

  Real-Time Sample Rate: 25 GS/s

  Resolution: 16-bit up to 200 MHz, 12-bit 200 MHz to 8 GHz

  Interface: USB 2.0, USB 3.0, USBTMC, Ethernet

  Applications: How to Capture an Electrical Transient Using an Oscilloscope, EMC Precompliance Testing

  Condition: Like New

  Cost New:

  Was:

  Price Now:

  $1,450.00

  In Stock

  Ordering Options

•

  ECO2G 2 GHz EMC Calibration Oscilloscope ESD Gun Verification

  SKU: 5501

  Sample Rate: 5 GSa/s (10 GSa/s ESR) ADC per analog channel

  Record Length: up to 500 Mpts

  Waveform Capture Rate: Up to 750,000 wfm/s (Sequence mode)

  Pre-Programmed Settings: IEC 61000-4-2 150pF/330 Ohm, All four R/C Combinations of ISO 10605

  Vertical Scales: 0.5 mV/div to 10 V/div

  Interfaces: USB Hosts, USB Device (USBTMC), LAN（VXI-11/Telnet/Socket, micro SD card, Pass/Fail, Trigger Out, HDMI

  Protocol Capabilities: Serial bus triggering and decoder - I2C, SPI, UART, CAN, LIN, CAN FD, FlexRay, I2S, MIL-STD-1553B, SENT, and Manchester

  Applications: How to Capture an Electrical Transient Using an Oscilloscope, EMC Precompliance Testing

  Cost New:

  Was:

  Price Now:

  $395.00

  IN STOCK

  Ordering Options

•

  R&S RTO1024 Used Oscilloscope (2 Channels)

  SKU: RO-RTO1024-CL

  Condition: 10 (Besides the 2 channels we blew)

  Warranty: 100 Days

  Bandwidth: 2 GHz

  Channels: 4 (Only 2 work)

  Bits of Resolution: Up to 16bits with High Definition Option

  Cost New:

  $21,950.00

  Was:

  $21,950.00

  Price Now:

  $8,500.00

  1 UNIT

•

  Siglent SDS5104X Digital Storage Oscilloscope

  SKU: 11510

  Bandwidth: 1 GHz

  Sample Rate: 5 GSa/s maximum (interleaving mode), 2.5 GSa/s (non-interleaving mode)

  Channels: 4

  Applications: How to Capture an Electrical Transient Using an Oscilloscope

  Cost New:

  Was:

  Price Now:

  $295.00

  Typically In Stock

  Ordering Options

•

  Tektronix TDS3052C Oscilloscope 500 MHz

  SKU: 12247

  Bandwidth: 500 MHz

  Channels: 2

  Sample rates on all channels: 5.0 GS/s

  standard record length on all channels: 10 k

  continuous waveform capture rate: 3,600 wfms/s

  Applications: How to Capture an Electrical Transient Using an Oscilloscope, EMC Precompliance Testing

  Cost New:

  Was:

  Price Now:

  $19.00

  In Stock

  Ordering Options

•

  Rohde & Schwarz (R&S) RTE1204 Digital Oscilloscope, 2 GHz, 4 channels, 5 Gsample/s, 10/40 Msample

  SKU: 30048

  Bandwidth: 2 GHz

  Realtime sampling rate: max. 5 Gsample/s on each channel

  Trigger types: edge, glitch, width, runt, window, timeout, interval, slew rate, data2clock, pattern, state, serial pattern, TV/video, serial bus trigger (optional)

  Channels: 4

  Applications: How to Capture an Electrical Transient Using an Oscilloscope, EMC Precompliance Testing

  Cost New:

  Was:

  Price Now:

  $950.00

  Inquire for Availability

  Ordering Options

•

  Tektronix DPO4054 Digital Oscilloscope, 4 Channels, 500 MHz

  SKU: 30047

  Bandwidth: 500 MHz

  Channels: 4

  Maximum Waveform Capture Rate: 3,700 wfms/s

  Sample Rates: Up to 5 GS/s on All Channels

  Applications: How to Capture an Electrical Transient Using an Oscilloscope, EMC Precompliance Testing

  Inquire for Availability

  View Product Cart

•

  ECO500M 500 MHz Oscilloscope, Pre-Programmed for Waveform Measurements

  SKU: 12157

  Bandwidth: 500 MHz

  Trigger type: Edge, Slope, Pulse width, Window, Runt, Interval, Dropout, Pattern, Video, Qualified, Nth edge, Setup/hold, Delay, Serial

  Peak detect: 200 ps

  Sequence: Up to 80,000 segments, interval between triggers = 1.3 μs min.

  Channels: 4

  Applications: How to Capture an Electrical Transient Using an Oscilloscope

  Cost New:

  Was:

  Price Now:

  $29.00

  In Stock

  Ordering Options

•

  Tektronix TDS7704B Oscilloscope, 4 Channels, 7 GHz

  SKU: 9010

  Bandwidth: 7 GHz

  Channels: 4

  Trigger Types: Edge, glitch, runt, width, transition, timeout, pattern, state, setup

  Waveform Capture Rate: 50 wfms/s

  Peak Detect: 400 ps

  Applications: How to Capture an Electrical Transient Using an Oscilloscope, EMC Precompliance Testing

  In Stock

  View Product Cart
