Electric Field Monitors

Weight: 10.6 oz.

Application/Test Type: Monitoring electric field strengths in GTEM's, Anechoic Chambers and other RF rooms for radiated immunity testing.

Battery: NiMH rechargeable batteries 4 x AA size (Mignon), 2500 mAh

Dimensions: 1.5 x 2.0 x 8 inches

Frequency Range: 100 kHz - 60 GHz

Display Interface: IEEE-488 Interface and RS-232 Interface

Frequency Range: 10 kHz - 40 GHz

Input: Up to 4 independent Probes

Overload: Probe dependent

Sensitivity: 0.15-3000 V/m; 15.0 mA/m - 30 A/m

Measurement Units: V/m, A/m, mW/cm² or W/m², % for shaped probes

Battery Life: 20 hours

Recharging Time: 2 hours

Calibration Status: NIST (5/22/2023)

PC Interface: Fiber Optic via USB (6 ft cable)

Weight: 62 g

Application/Test Type: Monitoring electric field strengths in GTEM's, Anechoic Chambers and other RF rooms for radiated immunity testing.

Battery: NiMH rechargeable batteries 4 x AA size (Mignon), 2500 mAh

Dimensions: 19.5 mm in height

Frequency Range: 100 kHz - 60 GHz

Application/Test Type: Monitoring electric field strengths in GTEM's, Anechoic Chambers and other RF rooms for radiated immunity testing.

Battery: rechargeable

Dynamic Range: 0.2 - 800 V/m depending on the probe used

Measurement Mode: Average, Peak, and Pulse

Standards Met: IEC/EN 61000-4-3

Weight: 0.2lbs.

Application/Test Type: EMC testing for CE, MIL and industrial EMC qualification. RF field strength monitoring for health, safety and industrial or military environmental control

Communication: Remote output monitoring is used for data analysis, storage and fast response close loop control.

Dimensions: 9 in x 2.25 in

Dynamic Range: 0.2 V/m-800 V/m

Weight: without enclosure 2.5 kg (6.25 lb) with enclosure 7.25 kg (16 lb)

Application/Test Type: Monitoring electric field strengths in GTEM's, Anechoic Chambers and other RF rooms for radiated immunity testing.

Communication: IEEE-488 (GPIB) USB 2.0, Test and Measurement class RS-232 (19200 Baud) Fiber Optic Serial (19200 Baud) reserved for connection to FM7004A Field Monitor Laser Fiber Optic Serial reserved for connection to one FL/PL 7000 series probe

Dimensions: without enclosure 48.3 x 4.5 x 25.4 cm (19.0 x 1.75 x 10.0 in) with enclosure 49.8 x 12.7 x 30.5 cm (19.6 x 5.0 x 12.0 in)

RF Connector: (2) E2000 compact duplex female for probe communication and safety fiber loop (2) FSMA for fiber connection to FM7004A
