Overview
The Boonton 57006 Peak Power Sensor is a high-performance RF power sensor designed for accurate peak power measurements across a wide frequency range. Operating from 500 MHz to 6 GHz, it offers fast response times and a broad dynamic range, making it well suited for engineers and technicians working with pulsed or complex RF signals.
With a dynamic input power range of -50 dBm to +20 dBm in peak mode, the sensor can capture both very low and relatively strong RF signals with excellent precision. Its fast rise time of less than 7 ns allows for detailed analysis of transient RF events and statistical signal behavior, making it a reliable tool for advanced RF measurement applications.
 |
 |
| Specifications: | |
|---|---|
| Frequency Range | 0.5 – 6 GHz |
| Dynamic Range | -50 to +20 dBm -60 to +20 dBm -40 to +20 dBm |
| Overload Rating | 1 W for 1 µs 200 mW |
| Fast Rise Time | <7 ns (70 MHz typical) |
| Slow Rise Time | <10 µs (350 kHz) |
Whether used for RF troubleshooting, signal validation, or peak power measurement, the Boonton 57006 provides dependable and repeatable results trusted by RF professionals. At The EMC Shop, we support the precision RF peak testing equipment calibration and rental services to ensure each unit performs to specification. Our team verifies the condition and functionality of the sensor so it is ready for use in demanding RF environments, including communications testing, radar development, and RF component evaluation.
