RF Power Measurement

R&S RF Power Meter & Sensor Rental Package

SKU: 45448

Frequency Range: DC - 60 GHz

Test Standards: IEC/EN 61000-4-3, DO-160 Section 20

Applications: EMC Precompliance Testing, Radiated Immunity Testing, RF Conducted Disturbances

RF Meter Channels: 1 to 4

Interface: GPIB, USB, LAN

Typically In Stock

VIEW PRODUCT Cart
RFPM1G-1000 Digital Power Meter with Directional Coupler

SKU: 4044

Frequency Range: 20 MHz to 1 GHz

RF Power Rating: 1000 W

Applications: Radiated Immunity, RF Conducted Immunity

In Stock

VIEW PRODUCT Cart
Boonton 4500B 30 MHz to 40 GHz Peak Power Analyzer

SKU: 8182

Frequency: 1.024 GHz ± 0.01%

Level Range: -50 to +20 dBm

Resolution: 0.1 dB

Output VSWR: 1.20 maximum

Absolute Accuracy: ±0.065 dB (±1.5%) at 0 dBm

Cost New:

Was:

Price Now:

$1,800.00 - $26,500.00

In stock

ORDERING OPTIONS
Keysight RF Power Meter/Sensor Rental Package (E4419B/E9304A)

SKU: 65771

Frequency Range: 9 kHz to 6 GHz

Application: Radiated Immunity

Sensitivity: -60 to +20 dBm

Connector: Type-N

Cost New:

Was:

Price Now:

$28.00 - $395.00

In Stock

ORDERING OPTIONS
Rohde & Schwarz NRP2 RF Power Meter

SKU: 1845-1

Frequency Range: DC to 110 GHz

Channels: 2 (Configurable up to 4)

Compatible Sensors: NRP-Z55, NRP-Z11

Cost New:

Was:

Price Now:

$395.00 - $9,500.00

In stock

ORDERING OPTIONS
Keysight E9300B Average Diode Power Sensor

SKU: 30114

Frequency Range: 10 MHz to 18 GHz

Connector: N-Type (m)

Dynamic Power Range: -30 dBm to +44 dBm

Compatible With: EPM (N1913A / 14A, E4418B / 19B), EPM-P (E4416A / 17A), and P-series (N1911A / 12A) power meters

Applications: Radiated Immunity

Cost New:

Was:

Price Now:

$495.00 - $4,750.00

Typically in Stock

ORDERING OPTIONS
Keysight E9304A H18 Power Sensor

SKU: 6233

Frequency Range: 9 kHz to 18 GHz

RF Power Range: -60 to +20 dBm

Connector Type: N-Type (m)

Applications: Radiated Immunity, Conducted Immunity

Test Standards: IEC 61000-4-3

VIEW PRODUCT
Keysight RF Power Measurement Equipment Package

SKU: 31456

Frequency Range: DC - 40 GHz (Sensor Dependent)

Power Range: -70 to +44 dBm

Measurement Types: Average, Pulse, Very Low Frequency (VLF)

Applications: Radiated Immunity Testing

Test Standards: IEC/EN 61000-4-3, MIL-STD-461 RS103, DO-160 Section 20, SAE J1113/4

Cost New:

Was:

Price Now:

$325.00 - $995.00

Typically In Stock

ORDERING OPTIONS
Keysight E9327A Power Sensor 50 MHz to 18 GHz

SKU: 8306

Frequency Range: 50 MHz to 18 GHz

Connector: N-Type

Power Range: -60 to +20 dBm

Maximum Power: +23dBm

Cost New:

Was:

Price Now:

$620.00 - $6,200.00

In Stock

ORDERING OPTIONS
Rohde & Schwarz NRT2 Power Reflection Meter

SKU: 6673

Frequency Range: 25 MHz to 4 GHz

Resolution: 16 bit

Accuracy of no-load output voltage: ±(0.4% of output voltage + 4 mV)

Connectors: BNC female

Power Rated Voltage: 100 V to 240 V

Cost New:

Was:

Price Now:

$445.00 - $4,395.00

In Stock

ORDERING OPTIONS
Rohde & Schwarz NRP RF Power Meter

SKU: 7140

Frequency Range: 10 MHz to 18 GHz

Channels: 4

Compatible Sensors: NRP-Z11

Cost New:

Was:

Price Now:

$600.00 - $6,095.00

In Stock

ORDERING OPTIONS
Ladybug LB479A Peak and Pulse Power Sensor 10 MHz - 8 GHz

SKU: 8289

Frequency Range: 10 MHz to 8 GHz (functional to 10 GHz)

Dynamic Range: -60 dBm to +20 dBm

Connector: SMA Male 3.5 mm

Match: 1.09:1 VSWR (27 dB Return Loss)

Time Base: +/- 50 ppm

Cost New:

Was:

Price Now:

$199.00 - $2,400.00

In Stock

ORDERING OPTIONS
