ETS-Lindgren HI-6005 Overview
The EMCO/ETS-Lindgren HI-6005 Electric Field Probe is a fully intelligent sensor enabling fast and accurate EMF measurements with industry-leading performance specifications. Optical coupling to a variety of readout options makes this probe ideally suited for a wide range of field monitoring applications. The HI-6100 Field Monitor provides manual functions and programmed control via IEEE-488 and RS-232 Serial Data Interfaces. Readings from up to four probes can be displayed simultaneously.
The ETS-Lindgren HI-6005 Field Probe is a fully intelligent sensor enabling fast and accurate EMF measurements with industry-leading performance specifications. Optical coupling to a variety of readout options makes this probe ideally suited for a wide range of field monitoring applications.
HI-6005 OPERATION
The HI-6005 can be used with the HI-6100 Field Monitor. It can also be connected to a personal computer using an optional HI-4413P Fiber Optic Modem or HI-4413USB Fiber Optic to USB Converter and ProbeView II™ software. The HI-6005 is a true 3-axis probe. When requested, X, Y, Z, and total field data can be reported.
[split]
|  |
| ETS-Lindgren HI-6005 Electric Field Probe Specifications | |
| Frequency Range | 100 kHz to 6 GHz |
| Frequency Response | 500 kHz to 2 GHz +1.0, -2.5 dB 2 to 5.5 GHz +3.5, -4.0 dB 5.5 to 6 GHz +2.0, -6.0 dB |
| Frequency Response with Correction | 100 kHz to 6 GHz ± 0.9 dB |
| Dynamic Range | 0.5 - 800 V/m (Single Range) |
| Resolution | 0.01 V/m |
| Isotropic Deviation | ± 0.5 dB @ 400 MHz |
| Linearity | ± 0.5 dB @ 27 MHz |
Standard Accessories:
HI-6005
Hard case
Certificate of Calibration
HI-4413USB
4.8 NiMH Charger model 491198-48
