Overview
Rent, buy or lease the Teseq NSG 1007-5 at The EMC Shop, same day shipping available.
The NSG 1007 series sources are microprocessor controlled and can be operated from an easy to use front panel keypad. Functions are grouped logically and are directly accessible from the keypad. This eliminates the need to search through various levels of menus and/or soft keys. A large analogue control knob can be used to quickly slew output parameters. This knob is controlled by a dynamic rate change algorithm that combines the benefits of precise control over small parameter changes with quick sweeps through the entire range.
Integrated system:
By combining a flexible AC/DC power source with a high performance power analyzer, the Teseq NSG 1007 sources are capable of handling complex applications that have traditionally required multiple instruments.
High crest factor
With a crest factor of up to 5:1, the NSG 1007 series sources can drive difficult nonlinear loads with ease. Since many modern products use switching power supplies, they have a tendency to draw high repetitive peak currents. The Teseq sources can deliver a repetitive peak current of up to 3 times their rated continuous current.
Applications
With precise output regulation and accuracy, the sources address many application areas for AC and DC power testing. They provide a high load current capability, multi or single phase output modes, and built-in power analyzer measurements. Additional features including line distortion simulation (LDS), arbitrary waveform generation, and programmable output impedance address requirements for product quality and regulatory compliance testing.
