Schwarzbeck NNHV 8123-800 Single Path High Voltage AMN (LISN)
SKU: 11158
Applications: Conducted Emissions, BCI Testing , Automotive EV EMCTest Standards: CISPR 25, MIL-STD-461, ISO 7637Max EUT DC Voltage: 1,000 VoltsMax EUT Current: 800 AmpsMax EUT AC Voltage (60Hz/400Hz): 700V/300VInquire for Lead Time -
Inquire for Availability -
Schloder CN 1240-125 125A Coupling Network
SKU: 30174
Frequency Range: DC, 15 Hz - 150 kHzInput Voltage: 0 V up to ± 300 VRated Voltage (AE - EUT): 250 V AC/DCRated current (AE - EUT): 125 AConnector: BNCInquire for Availability -
Keysight 33210A 10 MHz Arbitrary Waveform Generator
SKU: 1378
Waveforms: Sine and SquareInterfaces: USB, GPIB and LAN (LXI)Sampling Rate: 50 MSa/sResolution: 14-bitTypically in Stock -
Solar 9354-1 Transient Generator for MIL-STD-461 CS116
SKU: 10507
Applications: RF Current Monitoring, EMC BCI TestsTest Standards: MIL-STD-461 CS116Industry: Military EMC TestingTypically In Stock -
Com-Power CGO-505 Comb Generator 5 MHz - 1 GHz in 5 MHz step
SKU: 0659
AC Power Adapter: 6 VDC, 500 mA / 110VAC 60 Hz or 230 VAC 50 HzAntennas: 5 and 12 inch MonopoleApplication/Test Type: EMI Radiated Site Reference SourceBattery: 6V NiMH, 1 AhDimensions: 7 x 0.75 inches / 17.7 x 1.9 cm$395.00 - $3,275.00Typically in Stock -
ETS-Lindgren 7405 E & H Near Field Probe Set
SKU: sku-396
Weight: 2 lbs (0.91 kg)Current Rating: 800 mA (per line), 1.6 Amps (per pair)Dimensions: 10.8” x 4.5” x 3.8” (275 mm x 115 mm x 96 mm)Frequency Range: 150 kHz to 3 GHzIsolation: 150 kHz to 1.5 MHz: 35 dB to 55 dB (increasing linearly with the log of freq.) 1.5 MHz to 30 MHz: 55 dB$1,500.00 -
Schaffner NSG 2025-4 EFT / Burst Generator Built in Three Phase Coupler
SKU: 11294
Burst (EFT) 5/50 ns: Pulse conforms to IEC/EN 61000-4-4Burst frequency: 0.1 kHz - 1,000 kHzBurst time: Rise Time: 5ns ±20% (50 W, 10 - 90%) Pulse Width: 50ns ±30% (50 W and 1 W), 100ns ±50% open circuitCoupling: Line to reference ground (IEC 1000-4-4), selected lines together to reference ground, all lines to reference ground (common mode)Mains & EUT Connections: HV Coax (Direct); L, N and PE via Coupler$975.00 - $6,750.00In Stock -
Teseq INA 701 Magnetic Field Coil for IEC 61000-4-8 and IEC 61000-4-9
SKU: 30172
Max. Contin. Frequency Current Supply: 10 AMax. Short Term Frequency Current Supply: 30 A (3 s)Max. Contin. Frequency Field Strength Supply: 330 A/mMax. Short Term Frequency Field Strength Supply: 11100 A/mApplications: Radiated ImmunityInquire for Availability -
Solar 8616-5-TS-200-N 5uH EMI LISN
SKU: SOLA-8616-5-TS-200-N
Test Standards: MIL-STD-462, DO-160, FCC Part 18Applications: Military EMC Testing, Conducted Emissions TestingMax Current: 100 AmpsFrequency Range: 10 kHz – 30 MHzCoupling Capacitor: 0.25 µFTypically In Stock -
Schwarzbeck TEMP 8400 Tempest AMN (LISN)
SKU: 6991
Frequency Range: 9 kHz - 1 GHzMax. cont. current: 16 A, 25 A (Limited time, 15 mins)Max Voltage (DC to 400 Hz): 250 V ACInsertion loss (EUT – AE): Typ. 25 - 60 dBApplications: Conducted Emissions, BCI Testing , Automotive EV EMC$525.00 - $7,945.00Typically In Stock -
EMC Partner IMU-MGS Transient Generator
SKU: 11129
Conducted Immunity Setup and Testing: Surge Immunity (Combo/Ring/Telecom Waves), EFT/BurstTest Standards: IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-11Output Levels: up to 5kV$1,195.00 - $2,295.00Typically In Stock
