Diode Detection Power Sensors Test Equipment
-
Keysight E9300B Average Diode Power Sensor
SKU: 30114
Frequency Range: 10 MHz to 18 GHzConnector: N-Type (m)Dynamic Power Range: -30 dBm to +44 dBmCompatible With: EPM (N1913A / 14A, E4418B / 19B), EPM-P (E4416A / 17A), and P-series (N1911A / 12A) power metersApplications: Radiated Immunity$495.00 - $4,750.00Typically in Stock -
Boonton 51011A-EMC Special Purpose Dual Diode Sensor
Frequency Range: 10 kHz to 8 GHzRF Power Sensors: -60 to +20 dBm²Typically In Stock -
Boonton 51013-4E 160 kHz to 18 GHz Diode Power Sensor
SKU: sku-1042
Dynamic Range: -60 to +20 dBmFrequency Range: 160 kHz to 18 GHzOverload: 1 W for 1µs 300 mWRF Field Probe Max SWR: 100 kHz - 4 GHz 4 GHz - 10 GHz 10 GHz - 18 GHz -
Boonton 51013 100 kHz to 18 GHz Diode Power Sensor
SKU: sku-919
Dynamic Range: -60 to +20 dBmFrequency Range: 100 kHz to 18 GHzOverload: 1 W for 1µs 300 mWRF Field Probe Max SWR: 100 kHz - 4 GHz 4 GHz - 10 GHz 10 GHz - 18 GHz -
Boonton 51015(5E) Diode Power Sensor
SKU: 6462
Frequency Range: 100 kHz to 18 GHzDynamic Range: -50 to +30 dBmOverload Rating: 10 W for 1µs 2 WTypically In Stock -
Boonton 52018 10 MHz – 18.50 GHz Power Sensor
SKU: 6245
Frequency: 10 MHz to 18.5 GHzMeasurement range: -50 to +20 dBm CWZero set: ±1.8 nWNoise: 0.15 nW RMSInput SWR - max: 1.26:1 = 18.5 GHz$195.00 - $2,975.00In Stock -
AR PH2004 RF Power Sensor, 100 kHz - 18 GHz
SKU: 8705
Frequency Range: 100 kHz to 18 GHzDynamic Range: -60 to +20 dBmApplications: Radiated Immunity, Conducted ImmunityMax RF Input: 300 mW (1 Watt for 1mS )SWR: 1.30 to 1.70$3,095.00In stock -
Amplifier Research PH2000 RF Power Sensor, 10 kHz - 8 GHz
SKU: 8704
Frequency Range: 10 kHz to 8 GHzDynamic Range: -60 to +20 dBmApplications: Radiated Immunity, Conducted ImmunityMax RF Input: 300 mW (1 Watt for 1mS )SWR: 1.12 to 1.40$295.00 - $3,095.00In stock
