Transient Generators Test Equipment

ECO2G 2 GHz EMC Calibration Oscilloscope ESD Gun Verification

SKU: 5501

Sample Rate: 5 GSa/s (10 GSa/s ESR) ADC per analog channel

Record Length: up to 500 Mpts

Waveform Capture Rate: Up to 750,000 wfm/s (Sequence mode)

Pre-Programmed Settings: IEC 61000-4-2 150pF/330 Ohm, All four R/C Combinations of ISO 10605

Vertical Scales: 0.5 mV/div to 10 V/div

IN STOCK

VIEW PRODUCT Cart
DP7 High Voltage Probe for Surge Generator Waveform Verification

SKU: 6533

Bandwidth: DC - 70 MHz

Attenuation: 1:100 and 1:1000

Accuracy: ±2%

Input Voltage Range: < +700V for X100, < +7000V for X1000

Output Voltage: ≤ + 7000V

Cost New:

Was:

Price Now:

$145.00 - $1,850.00

IN STOCK

ORDERING OPTIONS
Surge4-5 Combo Wave Generator for IEC 61000-4-5 Testing

SKU: 11857

Standards Met: IEC/EN 61000-4-5, IEC/ISO 60601-1-2, VDE 0847 4-5

Applications: EMC Surge, CE Marking

Built in CDN Power Handling: 270 Volts and 16 Amps

Combination/Wave Surge Output Capability: 200 Volts to 4.4 kV

External Coupling: Data Lines (Surge), 3PH EUT

Ships Same Day

VIEW PRODUCT Cart
Pearson 101 Current Monitor for Surge Generator Output Verification

SKU: 11067

Weight: 23 ounces

Aperture: See data sheet

Connector type: BNC (UG-290A/U)

Current time product: 2.5 Ampere-second maximum

Dimensions: See data sheet

IN STOCK

VIEW PRODUCT
Thermo Keytek EMCPro Plus EMC Immunity Test System

SKU: 11054

1 review

Test Capabilities: Surge Immunity (Combo/Ring/Telecom Waves), EFT/Burst, Dips Interrupts & Variations

Standards Met: IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-11

Max EUT Voltage (w/ Built in CDN): 250 Volts

Max EUT Current (w/ Built in CDN): 16 Amps

EFT/Burst Pulse Output Capability: 4 kV

Cost New:

Was:

Price Now:

$1,695.00 - $22,975.00

In Stock

ORDERING OPTIONS
EFT-DLC-CAL Transducer Plate for Coupling Clamp Calibration

SKU: 12781

Connector Types: Fischer HV, SHV, BNC

Application: EFT Waveform Verification, IEC / EN 61000-4-4 Edition 3

Standards Met: Calibration according to IEC / EN 61000-4-4 Edition 3

Compatible Couplers: Any

Cost New:

Was:

Price Now:

$1,475.00

IN STOCK
Teseq NSG 5500 Automotive Immunity Generator

SKU: 10257

Applications: Automotive Electrical Disturbances, EV EMC Testing

Test Standards: ISO 7637

Max EUT DC Voltage (w/ Built In CDN): 60 Volts

Max EUT DC Current (w/ Built In CDN): 30 Amps

Peak Inrush Current Capability: 300 Amps

Inquire

VIEW PRODUCT Cart
3ctest EDS MAX30 ESD Simulator Gun

SKU: 141242

Output Voltage Range: 200 Volts to 30,000 Volts

Voltaage Resolution: 100V

Holding Time: 5 - 10 s

Test Standards: ISO 10605, IEC/EN 61000-4-2:2025

Remote & Automation Control: Via fiber optic interface

Typically In Stock

VIEW PRODUCT Cart
Teseq CDN ST08 Coupling Decoupling Network

SKU: 8413

Frequency Range: 10 kHz to 80 MHz

Application: CDN for screened eight lines with RJ45 connector

Current Rating: 1000 mA

EUT Connector: BNC 50 Ω

Common mode impedance (EUT Port) 10 kHz to 26 MHz: 150 Ω ±20 Ω

Cost New:

Was:

Price Now:

$1,600.00

Typically in Stock
CST1 ESD Current Target Calibration Kit DC - 4 GHz, 30 kV

SKU: 8539

Frequency Response: DC – 4 GHz S21 < ± 0.5 dB up to 1 GHz, < ± 1.2 dB up to 4 GHz

Input resistance: 1.00 Ohm - ± 1% 1.00 Ohm when match with 50 Ohm load

Max. IEC Pulse Amplitude: Verified up to ± 30 kV

Voltage Non-linearity: < 2% up to 20 kV, < 5% up to ± 30 kV

Standards: IEC 61000-4-2, ISO 10605, and many more

Cost New:

Was:

Price Now:

$475.00 - $5,940.00

In stock

ORDERING OPTIONS
AE Techron CR 600 Chattering Relay for DO-160 Section 19

SKU: sku-CR600

Coil Voltage: 24 V DC

Coil Current: 84 mA

Contact Rating: 30 A

Typical Pulse Voltage: > 700 Vpp

Typically In Stock

VIEW PRODUCT Cart
3ctest EDS MAX20 ESD Simulator Gun

SKU: 141241

Output Voltage Range: 500 Volts to 20kV

Step Voltage: 100V

Compliance Standards: IEC/EN 61000-4-2:2025

Pre-programmed IEC Test Routines?: Yes

Remote & Automation Control?: Yes (via fiber optic interface)

Cost New:

Was:

Price Now:

$475.00 - $8,975.00

Typically In Stock

ORDERING OPTIONS
