Test Type

Test Type Test Equipment

•

  EM Test CSS 500N10 Current Surge Generator, 8/20us Up To 10ka

  SKU: 30061

  Weight: approx. 66 lbs.

  Coupling: N/A

  Dimensions: 19"/6HU,

  Polarity: positive / negative / alternate

  Pulse current (short circuit): 0.4kA to 10kA +/-10%

  Inquire for Availability

  VIEW PRODUCT Cart

•

  Rohde & Schwarz (R&S) NRP-Z55 Thermal Power Sensor

  SKU: sku-714

  RF Field Probe Connector: 2.92 mm connector

  RF Field Probe Frequency Range: DC to 44 GHz

  RF Field Probe Maximum Input Power: 10 W (PK, 1 µs)

  RF Field Probe Measurement Accuracy: Measurement range: –35 dBm to +20 dBm

  Supply Voltage: Operation with R&S®NRP2 base unit or via USB on a Laptop/PC

  Cost New:

  Was:

  Price Now:

  $295.00

  ORDERING OPTIONS

•

  California Instruments OMNI 1-18i Impedance Matching Network

  SKU: 17109

  • Ideal for IEC 61000-3-3 and IEC 61000-3-11 Flicker testing

  • Built in compliance to TR/IEC 60725

  Inquire for Lead Time

  VIEW PRODUCT Cart

•

  Rohde & Schwarz (R&S) RTE1204 Digital Oscilloscope, 2 GHz, 4 channels, 5 Gsample/s, 10/40 Msample

  SKU: 30048

  Bandwidth: 2 GHz

  Realtime sampling rate: max. 5 Gsample/s on each channel

  Trigger types: edge, glitch, width, runt, window, timeout, interval, slew rate, data2clock, pattern, state, serial pattern, TV/video, serial bus trigger (optional)

  Channels: 4

  Applications: How to Capture an Electrical Transient Using an Oscilloscope, EMC Precompliance Testing

  Cost New:

  Was:

  Price Now:

  $950.00

  Inquire for Availability

  ORDERING OPTIONS

•

  Rent RF Conducted Immunity Test System per IEC 61000-4-6

  SKU: 0699

  Test Capabilities: RF Conducted Immunity

  Standards Met: IEC/EN 61000-4-6

  Applications: CE Marking, Medical Devices, Industrial Machinery, Electronics & IT

  CDN Test Levels (w/ built-in amplifier): 100Vrms

  BCI Test Levels (w/ built-in amplifier): 30V

  IN STOCK

  VIEW PRODUCT Cart

•

  GRC Series Ground Cable w/ 470k Ohm Resistors for ESD Voltage Bleeding

  SKU: 30180

  Total Resistance: 1 MOhm (± 1%)

  Connector Type: 1/4" Spade

  Cable Voltae Withstand: 40kV (150 degrees C)

  Length: 1.5, 2 and 3 Meters

  Resistance: HV Precision Resistors (1% tolerance)

  Cost New:

  Was:

  Price Now:

  $279.00 - $499.00

  In Stock

  ORDERING OPTIONS

•

  Rohde & Schwarz NRP6A Average Power Sensor, 8 kHz - 6 GHz

  SKU: 10679

  Frequency Range: 8 kHz to 6 GHz

  RF Power Range: 100 pW to 200 mW (–70 dBm to +23 dBm)

  Max Average Power: 1 Watt

  Peak Envelope Power: 2 Watts for 10 µs (then Kaploowee)

  Typically In Stock

  VIEW PRODUCT Cart

•

  Keysight 34460A Digital Truevolt Multimeter, 100 mV to 1,000 V DCV, 100 mV to 750 V ACV

  SKU: sku-670

  VIEW PRODUCT Cart

•

  Tektronix DPO4054 Digital Oscilloscope, 4 Channels, 500 MHz

  SKU: 30047

  Bandwidth: 500 MHz

  Channels: 4

  Maximum Waveform Capture Rate: 3,700 wfms/s

  Sample Rates: Up to 5 GS/s on All Channels

  Applications: How to Capture an Electrical Transient Using an Oscilloscope, EMC Precompliance Testing

  Inquire for Availability

  VIEW PRODUCT Cart

•

  Empower Model 2175 RF Amplifier High Power CW, Modulated, & Pulse, 80 – 1000 MHz, 500 Watts

  SKU: 10654

  Weight: 68 LBs

  Dimensions: 17.5 x 5.25 x 22

  Frequency Range: 80 – 1000 MHz

  Gain: 60 dB min

  Impedance: 50 ohms nominal

  VIEW PRODUCT Cart

•

  Amplifier Research FP7060 E-Field Probe Kit, 27 MHz – 60GHz, 0.7–300 V/m

  SKU: 11650

  Weight: 350g approx

  Application/Test Type: electric field measurement instrument for use in EMC and EMI applications

  Battery: 2 built-in NiMH batteries, size AA, rechargeable, changed by operator, 40 hours operating life per charge.

  Communication: 10 m glass cable

  Dimensions: Approx. 420 x 85 x 65 mm including base and probe

  VIEW PRODUCT Cart

•

  Teseq INA 5530 ISO 7637 Automotive Pulse 3a & 3b Verification Kit

  SKU: sku-634

  Impedance: 50 Ohms

  RF Connector: Input BNC male Output BNC female

  Voltage Rating: 1.2 kV, 3Wrms

  VIEW PRODUCT Cart
