Overview

The EMC Shop stocks a variety of broadband RF power amplifiers, primarily for EMC testing. Our inventory containts current, solid state technology up to 40 GHz and boasts the smallest amplifiers for convenient transport. Traveling Wave Tube (TWT) Amplifiers for military EMC and RF immunity are also in stock. Efficiently meet the test levels of any radiated immunity and susceptibility test standard.

RF Power Amplifiers for EMC Testing - Rentals & Sales

Applications

EMC Amplifier Applications

IEC 61000-4-3 - Can be completed with two solid state amps
MIL-STD 461 RS - 100W solid state from 6 to 18 GHz coupled with a High Gain Horn to achieve 200V/m. Solid State 40 Watt amps to 40 GHz available.
IEC 61000-4-6 - One solid state amp up to 1 GHz (dual band)
DO-160 - One solid state EMC amp
Automotive - CW and Pulse solid state amps under 6 GHz
Pulsed RF Power Ampifiers

Other RF Amplifier Applications

Electronic Warfare
Communications
Radar Testing

Browse IEC 61000-4-6 Test Equipment

Amplifier Band Coverage Guide

RF Amplifiers
0-3 kHz	10 kHz	100 MHz	250 MHz	500 MHz	1 GHz	2 GHz	4 GHz	6 GHz	10 GHz	20 GHz	40 GHz
									18 GHz - 40 GHz
								6 GHz - 18 GHz
						2 GHz - 8 GHz
					1 GHz - 6 GHz
					1 - 2 GHz
				700 MHz - 4.2 GHz
		80 MHz - 1 GHz
	10 kHz - 1 GHz
	10 kHz - 400 MHz
	10 kHz - 250 MHz
DC - 300 kHz

Popular Amplifiers

Rent Keysight N9048B CISPR 16 EMI Receiver

Get Started

The EMC Shop has a large assortment of broadband amplifiers for Radiated Immunity testing.

Contact Now

RF Power Amplifiers Categories

DC/Low Frequency High Power Amplifiers

Solid State High Power Amplifiers

TWT Power Amplifiers

18 GHz - 40 GHz RF Amplifiers

Pulse Amplifiers

RF Power Amplifiers Test Equipment, Systems & Solutions

Amplifier Research 1000W1000G RF Amplifier 80MHz - 1000MHz, 1000 Watts CW

SKU: sku-2173

Max Frequency: 1 GHz

Min Frequency: 80 MHz

Output Power: 1000 Watts

Applications: Radiated Immunity, Automotive, Medical, Military and Aerospace

Standards: IEC 61000-4-3, ISO 11451-2, MIL-STD 461, DO-160

Gain: 60dB

AC Input Power: 200-240V/1PH/4kVA

Cooling: Forced Air

RENTAL ONLY

View Product Cart
SS18G-10 Solid State High Power Amplifier 1 - 18 GHz

SKU: 7312

Frequency Range: 1 - 18 GHz

Gain: 40 / 44 ±4

Line Power: 400 VA

Weight: 14 kg

Input Power: 0 dBm (1 mW) max.

RF Input: SMA-f

RF Output: SMA-f

MSRP:

Was:

Price Now:

$5,250.00

IN STOCK

Ordering Options
SS6G-100 Solid State High Power Amplifier 0.7 - 6.0 GHz

SKU: 8221

Frequency Range: 0.7 GHz - 6.0 GHz

Input Power: 0 dBm (1 mW) max

RF Connectors Input: N-f

RF Output: N-f

Vibration and Shock: MIL-STD-810 G

MSRP:

Was:

Price Now:

$5,975.00

In Stock

Ordering Options
Amplifier Research 40T26G40A Millimeter Wave TWTA

SKU: 7360

Frequency Range: 26.5 - 40 GHz

Output Power: 40 watts

Linear at 1dB Compression: 10 watts minimum

Flatness: ± 8 dB

Input for rated Output: 1.0 milliwatt maximum

Gain (at maximum setting): 46 dB minimum

Gain Adjustment (continuous range): 35 dB minimum

Input Impedance: 50 ohms, VSWR 2.0:1 maximum

Output Impedance: 50 ohms, VSWR 2.5:1 typical

Primary Power: 99-260 V AC, 50/60 Hz single phase, 850 VA maximum

Noise Power Density: Minus 60 dBm/Hz (maximum), Minus 70 dBm/Hz (typical)

Harmonic Distortion: Minus 20 dBc maximum, Minus 28 dBc typical

Cooling: Forced air (self contained fans), air entry and exit in rear

Typically In Stock

View Product Cart
Amplifier Research 2500A225B High Power Low Frequency RF Amplifier

SKU: sku-1314-1

Max Frequency: 225 MHz

Min Frequency: 10 kHz

Output Power: 2500 Watts

Applications: RF Conducted Immunity, Medical

Standards: IEC 61000-4-6, MIL-STD 461 CS114

AC Input Power: 380-415V/3PH/8.5kVA

Gain: 64 dB

Connector Type: 7/16 DIN

Typically In Stock

View Product Cart
SS18G-35 RF Power Amplifier

SKU: 5568

Frequency Range: 6 - 18 GHz

Output Power PN min / typ: 35 / 40

Gain min / typ dB: 45.4 / 50 ±4

Harmonics 2nd / 3rd dBc: 12 / 20

Line Power: 850

Dimensions (H, D) 19"-System: 3 HU, 430 mm

Weight: 21kg

In Stock

View Product Cart
SS1G-500 Solid State Amplifier 80 MHz - 1 GHz with 500 Watts

SKU: SS1G-500

Max Frequency: 1 GHz

Min Frequency: 80 MHz

Output Power: 500 Watts

Applications: Radiated Immunity, Automotive, Medical, Military and Aerospace

Standards: IEC 61000-4-3, ISO 11451-2, MIL-STD 461, DO-160

Gain: 57dB

AC Input Power: 200-240V/1PH/3.3kVA

Cooling: Forced Air

In Stock

View Product Cart
SS1G-100 100 Watt RF Power Amplifier 80 MHz - 1 GHz

SKU: 6201

Max Frequency: 1 GHz

Min Frequency: 80 MHz

Output Power: 100 Watts

Applications: Radiated Immunity, Automotive, Medical, Military and Aerospace

Standards: IEC 61000-4-3, ISO 11451-2, MIL-STD 461, DO-160

Gain: 50dB

AC Input Power: 200-240V/1PH/1kVA

Cooling: Forced Air

IN STOCK

View Product Cart
SS250M-500 Low Frequency EMC Amplifier

SKU: 5746

Max Frequency: 250 MHz

Min Frequency: 9 kHz

Output Power: 500 Watts

Applications: RF Conducted Immunity, Medical

Standards: IEC 61000-4-6, MIL-STD 461 CS114

AC Input Power: 200-240V/1PH/2kVA

Gain: 57dB

Videos: Gain Measurement, Setting up for Remote Control

In Stock

View Product Cart
SS3200M-CW500-P1000 High Power Amplifier for Automotive Testing

SKU: 5839

Max Frequency: 800 MHz

Min Frequency: 3.2 GHz

Output Power: 1000 Watts Pulse, 500 Watts CW

Applications: Radiated Immunity, Automotive EV EMC Testing

Standards: FMC 1278, GMW3097

Gain: 60dB

AC Input Power: 180-240V/1PH/3kVA

In Stock

View Product Cart
Amplifier Research 10W1000C 10 Watt 500 KHz - 1 GHz RF Power Amplifier

SKU: sku-1153

Max Frequency: 1 GHz

Min Frequency: 500 kHz

Output Power: 10 Watts

Applications: Radiated Immunity, Automotive, Medical, Military and Aerospace

Standards: IEC 61000-4-3, ISO 11451-2, MIL-STD 461, DO-160

Gain: 40dB

AC Input Power: 90-132V/1PH/300VA

Cooling: Forced Air

View Product Cart
E&I / ENI 2200L Class A Linear RF Power Amplifier

SKU: 0725

AC Input: 104 – 240 Volts 8.4 A @ 120 V4.2 A @ 240 V

Frequency range: 10 KHz to 12 MHz

Gain: 53 dB (nominal)

Gain Flatness: +/- 1.5 dB

Input Power for Rated Pout: 1 mW

Output Impedance: 50Ω / 2:1 maximum

Protection: Input: Unit will withstand input signal of +13 dBm without damage (1.0 V rms) max. and infinite load VSWR.

Rated Power Output: 200 Watts (P1dB)

MSRP:

Was:

Price Now:

$995.00

In Stock

Ordering Options
