RF Power Amplifiers

RENTING RF POWER AMPLIFIERS

The EMC Shop stocks a variety of broadband RF power amplifiers, primarily for EMC testing. Our inventory containts current, solid state technology up to 40 GHz and boasts the smallest amplifiers for convenient transport. Traveling Wave Tube (TWT) Amplifiers for military EMC and RF immunity are also in stock. Efficiently meet the test levels of any radiated immunity and susceptibility test standard.

CONNECT NOW

Rent RF Power Amplifiers - Ship Same Day

EMC AMPLIFIER APPLICATIONS

IEC 61000-4-3 - Can be completed with two solid state amps
MIL-STD 461 RS103 - 100W solid state from 6 to 18 GHz coupled with a High Gain Horn to achieve 200V/m. Solid State 40 Watt amps to 40 GHz available.
IEC 61000-4-6 - One solid state amp up to 1 GHz (dual band)
DO-160 Section 20 - One solid state EMC amp
Automotive - CW and Pulse solid state amps under 6 GHz
- ISO 11452-2
- ISO 11451-2
- SAE J1113/4
- Manufacturer Specific
Pulsed RF Power Ampifiers

RESOURCES

OTHER RF AMPLIFIER APPLICATIONS

Electronic Warfare
Communications
Radar Testing

RF Amplifiers Selection Chart
0-3 kHz	10 kHz	100 MHz	250 MHz	500 MHz	1 GHz	2 GHz	4 GHz	6 GHz	10 GHz	20 GHz	40 GHz
									18 GHz - 40 GHz
								6 GHz - 18 GHz
						2 GHz - 8 GHz
					1 GHz - 6 GHz
					1 - 2 GHz
				700 MHz - 4.2 GHz
		80 MHz - 1 GHz
	10 kHz - 1 GHz
	10 kHz - 400 MHz
	10 kHz - 250 MHz
DC - 300 kHz

ONLINE RF POWER AMPLIFIER RENTALS

Rent Keysight N9048B CISPR 16 EMI Receiver

Sold out

/month

Sold out

/month

Sold out

/month

Sold out

/month

RF Power Amplifiers Categories

10 kHz - 250 MHz RF Amplifiers

10 kHz - 400 MHz RF Amplifiers

80 MHz - 1 GHz RF Amplifiers

1 GHz - 2 GHz RF Amplifiers

700 MHz - 4.2 GHz RF Amplifiers

1 GHz - 6 GHz RF Amplifiers

2 GHz - 8 GHz RF Amplifiers

6 GHz - 18 GHz RF Amplifiers

18 GHz - 40 GHz RF Amplifiers

40 GHz - 60 GHz Microwave Amplifiers

DC/Low Frequency Power Amplifiers

4 Quadrant Current/Voltage Amplifiers

High Power Pulse Amplifiers

TWT Power Amplifiers

RF Power Amplifiers

SS6G-175 Radiated Immunity EMC Amplifier

SKU: 7250

Frequency Range: 1 GHz - 6 GHz

Gain: 54.8 / 58 ±3 (1 to 4 GHz), 53 / 56 ±3 (4 to 6 GHz)

Harmonics: 20 dBc

Output Power: 300 Watts from 1 - 4 GHz, 200 Watts from 4 to 6 GHz

Weight: 121 Lbs

Typically In Stock

VIEW PRODUCT Cart
Amplifier Research 50S1G6 Solid-State Amplifier

SKU: 2203

Weight: 62.5 lbs.

Dimensions: 50.3 x 20.3 x 54.6 cm 19.8 x 8.0 x 21.5 in

Flatness: Small Signal Flatness:±1.5 dB typical ±2.5 dB maximum

Frequency Range: 0.7 – 6 GHz

Impedance: 50 ohms

VIEW PRODUCT Cart
SS1G9k RF Conducted Susceptibility Power Amplifier

SKU: 172501

Frequency Range: 9 kHz - 1 GHz

Output Power (P1dB): 5 Watts to 1,000 Watts

Harmonics: 20 dBc typ

RF Connectors: N (f) - Front or Rear

Inquire for Availability

VIEW PRODUCT Cart
SS3100M-P1000 Automotive Pulsed Radiated Amplifier

SKU: 8345

Frequency Range: 1.2 GHz to 3.1 GHz

Pulse Width Max.: 100 µs

Gain: 60 ± 2 dB

Harmonics 2nd / 3rd: 30 dBc

App Note: Utilizing Solid State and CW Amplifiers for Radiated Pulse Immunity Testing

Typically in Stock

VIEW PRODUCT Cart
ETS-Lindgren 8000-030 RF Amplifier 10 kHz - 400 MHz, 260 Watts CW

SKU: 5022

Frequency Range: 10 kHz to 400 MHz

Nominal Output Power: 260 W

Gain Variation: 3 dB

Harmonics: -20 dBc Maximum

Output Impedance: 50 Ω

Cost New:

Was:

Price Now:

$1,595.00

Typically In Stock

ORDERING OPTIONS
Amplifier Research 250W1000C CW Solid State Amplifier, 80 MHz - 1 GHz, 250 Watts

SKU: 1760

Max Frequency: 1 GHz

Min Frequency: 80 MHz

Output Power: 250 Watts

Applications: Radiated Immunity, Medical, Military and Aerospace

Standards: IEC 61000-4-3, ISO 11451-2, MIL-STD 461, DO-160

Typically in Stock

VIEW PRODUCT Cart
SS6G-200A 1 - 6 GHz, 200 Watt Solid State RF Amplifier

SKU: 6284

Frequency Range: 700 MHz - 6 GHz

Gain: 55 dB minimum

Input: 180 - 240 VAC, 2500 watts

Output: POWER OUTPUT @ 1dB COMPRESSION : Typical: 200 watts minimum, 225 watts typical

Impedance: 50 ohms

In STOCK

VIEW PRODUCT Cart
Amplifier Research KAA2030

SKU: 427211

Output Power: 200 Watts

Frequency Range: 500 KHz - 40 MHz

Max. Gain: 52 dB minimum

Input for Rated Output: 2.0 milliwatt maximum

1 Available

VIEW PRODUCT Cart
SS100M9K Low Frequency EMC Power Amplifier Series

SKU: 9161

Frequency Range: 9 kHz to 100 MHz

Power Output: 100-5000 Watts

Input Power: 0 dBm (1 mW) nom.

RF Output Connector: 7/16 DIN Output

Applications: Radiated Immunity

Inquire for Availability

VIEW PRODUCT Cart
Amplifier Research 5S1G4M3 Solid State Amplifier

SKU: 10769

Frequency Response: 0.8 GHz to 4.2 GHz instantaneously

Rated Power Output: 6.5 watts min.

Input for Rated Output: 1.0 milliwatt max.

Flatness: ±1.5 dB typical, ±2.0 dB maximum

Gain (at max. setting): 37 dB min.

Cost New:

Was:

Price Now:

$2,975.00

In Stock

ORDERING OPTIONS
Milmega AS0822-100 Broadband Amplifier

SKU: 5920

Frequency Range: 0.8 GHz - 2.2 GHz

Watts: 100

RF Connector: Type N female

Noise figure (max): 6.0 dB

Gain variation: ± 2.0 dB

In Stock

VIEW PRODUCT Cart
AE Techron 7234 Industrial Power Amplifier/Battery Simulator

SKU: 4302

AC Power Adapter: Single phase, 120 VAC, 60 Hz, 20A service; (220-240 VAC, 50-60 Hz, 10A service model available)

Frequency Range: DC—300 kHz (1 watt): +1 to -2.0 dB

Gain: Voltage Mode: 20 volts/volt Current Mode: 5 amperes/volt

Impedance: 20k ohm differential

Max input power: ±10V, balanced or unbalanced

Cost New:

Was:

Price Now:

$595.00

Typically In Stock

ORDERING OPTIONS
