Rent programmable AC power sources from Chroma, Ametek/California Instruments, Keysight and other manufacturers. The EMC Shop stocks calibrated test equipment for signal integrity, product and compliance. Programmable AC power sources come configured with test sequences to simulate electrical phenomena along electrical mains.

Get Application Support, Pricing, Lead Time and More: CONTACT FORM

VIDEO OVERVIEW - AC POWER SUPPLY RENTALS

RESOURCES:

Programmable AC Power Sources Test Equipment, Systems & Solutions

California Instruments CSW5550 Programmable Power Source

SKU: 5600

Frequency Range: 16.00 - 81.91 Hz (0.01 Hz resolution), 81.0 – 819.1 Hz (0.1 Hz resolution), 820 – 5000 Hz (1 Hz resolution)

Voltage Range: 0 - 312 Volts

Applications: Harmonic Waveform Generation for IEC 61000-3-X Tests

Power: 5.5 kVA to 33.3 kVA

Voltage: 0 to 312 V

Current: 0 to 288 A

Input Power: 220 VAC, 3-Phase

Cost New:

Was:

Price Now:

$875.00

In Stock

Ordering Options
California Instruments Asterion AST6003 Programmable AC & DC Power Supply

SKU: 30159

Applications: Aerospace, Aircraft And Aviation EMC Testing, Automotive EV EMC

Phase: 1 phase and 3 phase

Output Power: 6,000 VA/6,000 W; 2,000 W, maximum per phase

Test Standards: EN/IEC 61000-4-13

Inquire for Lead Time

View Product Cart
Pacific SmartSource 3150ADF High Power AC Source

SKU: 30030

Frequency Range: 45 to 500 Hz

Programming Resolution: 0.01 Hz

Max Output Voltage: 0 – 350 VLN / 0-600 VLL

Power Output: 15 kVA

Max. AC Current: 41 Amps AC (21 Amps DC) rms

In Stock

View Product Cart
Chroma 61602 Programmable AC Power Source

SKU: 7237

Power (Output Rating-DC): 500 W

Frequency Range: DC, 15 Hz - 1 KHz

Current Output (per phase): 4 A /2 A (212 V / 424 V)

Current Input (per phase): 18A Max. @ 90V

Bandwidth (Harmonics & Inter-harmonics Simulation): 2400 Hz

Typically In Stock

View Product View Product
Elgar CW801M AC Power Supply

SKU: 5947

Power: 800 VA

Voltage: 90 - 264 VAC

Current: 13 ARMS max

Frequency: 47 to 63 Hz

Phases: Single-phase

Power Factor: >0.99 typical at full load nominal line

Efficiency: >73% typical at full load

Cost New:

Was:

Price Now:

$195.00

In Stock

Ordering Options
ELGAR SW5250A - AC Power Source

SKU: 12361

Output Voltage Range: 0 to 312 Vrms L-N

Test Standards: MIL-STD-704, DO-160 and ABD100

Output Current Per Phase: 16 Amps at 135 Volts, 13 Amps at 270 Volts

Frequency Range: DC/2Hz to 6 kHz

Weight: 127 Lbs

Input: 87-264VRMS (L-L), 3-wire

Cost New:

Was:

Price Now:

$700.00

In Stock

Ordering Options
Chroma 61601 Programmable AC Source

SKU: 30165

Applications: Military and Aerospace and more

Test Standards: IEC 61000-3-2

Output Rating: 0 - 300 VAC, 500 VA, 15 - 1000 HZ

Frequency Range: 15 Hz – 100 0Hz

RMS: 4A/2A (150V/300V)

In Stock

View Product Cart
Rent Chroma 61605 Single Phase AC Power Source

SKU: sku-2125

Weight: 71 kg/165.2 lbs

Current rating: 120 amps

Dimensions: 400 x 482 x 600 mm (15.75 x 19 x 24 in)

Frequency Range: DC, 15 Hz - 1.2 kHz (.15% accuracy)

Output current: 16 Amps RMS (96 Amps Peak)

Output voltage: 6000 VA max, 2000 VA per phase

Voltage ranges: 150-300 Volts

Cost New:

Was:

Price Now:

$1,295.00

Ordering Options
California Instruments 1501iX Programmable AC Power Source

SKU: 30090

Weight: per Chassis: Net: 61 lbs / 28 Kg, Shipping: 115 lbs / 52 Kg

Current rating: 120 amps

Dimensions: Height: 7” (178 mm), Width: 19” (483 mm), Depth: 24” (610 mm) (depth includes rear panel connectors)

Frequency Range: 16.00 - 81.91 Hz (0.01 Hz resolution) 81.0 – 819.1 Hz (0.1 Hz resolution) 820 – 1000 Hz (1 Hz resolution)¹

Voltage ranges: 150-300 Volts

Applications: Conducted Immunity

Test Standards: IEC-61000-4-29

Cost New:

Was:

Price Now:

$5,400.00

In Stock

Ordering Options
Chroma 61704 3-Phase AC Power Source for MIL-STD-704 and RTCA DO-160 Testing

SKU: sku-872

Weight: 71 kg/165.2 lbs

Current rating: 120 amps

Dimensions: 400 x 482 x 600 mm (15.75 x 19 x 24 in)

Frequency Range: DC, 15 Hz - 1.2 kHz (.15% accuracy)

Output current: 16 Amps RMS (96 Amps Peak)

Output voltage: 6000 VA max, 2000 VA per phase

Voltage ranges: 150-300 Volts

View Product Cart
Rent APT 6010 Automated AC Power Source

SKU: 2668

Voltage: 300 Volts

Frequency: 9.2 Amps

Frequency Range: 500 Hz

Phase: Single-Phase

Applications: Conducted Immunity

Cost New:

Was:

Price Now:

$199.00

In Stock

Ordering Options
EM Test NetWave 7.3 Programmable AC & DC Power Supply

SKU: 30176

Bandwidth: DC - 5 kHz

Output Voltage: 0 V - 360 VAC (RMS), 0 V - +/-500 VDC

Output Current: 26 A (RMS) continuous, 47 A (RMS) short-term (max. 3 s), 200 A repetitive peak (@max. 300 VAC, 360 VDC)

Number of Lines: 1

Frequency Accuracy: 100 ppm

Applications: Military and Aerospace, Automotive EV EMC

Test Standards: EN/IEC 61000-4-13, EN/IEC 61000-4-14

Additional Test Standards: EN/IEC 61000-4-27, -29; EN/IEC 61000-3-2, -3, -11, -12

Inquire for Lead Time

View Product Cart
