EN/IEC 61000-3-2

(Showing 12 of 12)

Meet harmonics and flicker test standards IEC 61000-3-3 using the same power source. "Electromagnetic compatibility (EMC) - Part 3-2 Limits for harmonic current emissions (equipment input current ≤ 16 A per phase)"

The EMC Shop stocks test equipment used to evaluate and certify electronic products according to EN/IEC 61000-3-2. Rentals ship same day, and can be delievered overnight to allow for immediate product testing.

The EMC Shop stocks equipment fo IEC 61000-3-2.

Inquire

The EMC Shop stocks equipment fo IEC 61000-3-2. Contact

Equipment can be grouped into one of 4 classes based on the following criteria as evaluated by the IEC committee members:

Number of pieces of equipment in use (how many (volume) are being used by consumers)
Duration of use (number of hours in operation)
Simultaneity of use (are the same type of equipment used on the same time frame)
Power consumption
Harmonics spectrum, including phase (how clean or distorted is the current drawn by the equipment)

After all the above criteria are taken into consideration equipment are classified as follows:

Class A
- Balanced three-phase equipment
- Household appliances, excluding equipment identified by Class D
- Tools excluding portable tools
- Dimmers for incandescent lamps
- Audio equipment
- Everything else that is not classified as B, C or D
Class B
- Portable tools
- Arc welding equipment which is not professional equipment
Class C
- Lighting equipment
Class D
- Personal computers and personal computer monitors
- Television receivers

Test Setup Circuit for Current Harmonics Mesaurements to IEC 61000-3-2

Show 12

EN/IEC 61000-3-2 Test Equipment, Systems & Solutions

Yokogawa WT5000 Precision Power Analyzer

SKU: 8802

Input Elements: 7

Max Current (per channel): 30 Amps

Max Voltage (per channel): 1000 Volts

Harmonics Measurement Standards: IEC 61000-3-2, IEC 61000-3-3, IEC 61000-3-12

In Stock

View Product Cart
Yokogawa WT333E Digital Power Meter with Harmonics Measurement Option

SKU: 8780

Input Elements: 3

Max Current (per channel): 20 Amps

Max Voltage (per channel): 600 Volts

Options: G5

Harmonic Measurement Standards: IEC 61000-3-2, IEC 61000-3-3, IEC 61000-3-12

In Stock

View Product Cart
NEO Messtechnik PQA8000 Mobile Power Quality Analyzer

SKU: sku-2225

INQUIRE

View Product Cart
PHFA Harmonics and Flicker Analyzer

SKU: 10451

Standards Met: IEC/ISO 60601-1-2, IEC 61000-3-2, IEC 61000-3-3, IEC/EN61000-4-7, IEC/EN61000-4-15

EUT Power Handling: 1PH/16 Amps

Max Current (with LDPS Source): 16 Amps (5 Amps)

Max Voltage (with LDPS Source): 690 Volts (630 Volts)

Cost New:

Was:

Price Now:

$3,500.00

IN STOCK
Yokogawa WT500 Mid-Range Power Analyzer

SKU: 8767

Input Elements: 2

Max Current (per channel): 40 amps

Max Voltage (per channel): 1000 volts

Options: G5

Harmonic Measurement Standards: IEC 61000-3-2, IEC 61000-3-3, IEC 61000-3-12

Cost New:

Was:

Price Now:

$670.00

In Stock

Ordering Options
Yokogawa WT3000 Power Analyzer with Harmonics Measurement Option

SKU: 8775

Input Elements: 4

Max Current (per channel): 6.3 Amps

Max Voltage (per channel): 250 Volts

Options: G5

Harmonic Measurement Standards: IEC 61000-3-2, IEC 61000-3-3, IEC 61000-3-12

In Stock

View Product Cart
LDPS AC Power Source, 1 kW up 4.4 Amps

SKU: 8549

Current ranges: ±24mA to ±400A pk in fifteen ranges

Sampling rate: 300 samples per second

Standards Met: IEC/ISO 60601-1-2, IEC 61000-3-2, IEC 61000-3-3

Additional Standards Met: IEC 61000-4-7 , IEC/EN61000-4-15

Voltages Ranges: 115V (±200V pk), 230V (±400V pk)

IN STOCK

View Product Cart
EM Test DPA 500N Power Analyzer for Harmonics & Flicker

SKU: sku-242

Standards Met: IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11

Application/Test Type: Medical Device EMC Testings

Typically In Stock

View Product Cart
EM Test DPA 503N Flicker & Harmonics Analyzer

SKU: 11286

Standards Met: IEC 61000-3-11, IEC 61000-3-12, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-7, IEC 60601-1-2 and more

Max Current (per Channel): 32 Amps

Applications: Medical Device EMC Testing

Matching Impedance Network: EM Test AIF 503N

Cost New:

Was:

Price Now:

$975.00

Usually ships in 24 hours.

Ordering Options
Teseq Profline 2100-1 Single-Phase Measurement System, AC source for Harmonics & Flicker

SKU: 11121

Test Standards: IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11

Application/Test Type: Medical Device EMC Testing

EUT Power: Single Phase AC up to 16 Amps

Typically In Stock

View Product Cart
Yokogawa WT1800 High Performance Power Analyzer

SKU: 12351

Input Elements: 5

Max Current (per Channel): 5 Amps

Max Voltage (per Channel): 1,000 Volts

Options: B5, G5, DT

Harmonic Measurement Standards: EN/IEC 61000-3-2, EN/IEC 61000-3-12

Cost New:

Was:

Price Now:

$695.00

IN STOCK

Ordering Options
Teseq NSG 1007 Programmable AC and DC Power Sources for IEC 61000-3-2 and -3-3

SKU: 11494

Test Standards: IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11

Application/Test Type: Medical Device EMC Testings

Inquire for Availability

View Product Cart
